EDAN LX3 4D Colour Doppler Ultrasound Machine

Product Description

The Medical Solution Company is highly acknowledged as a trader, importer, wholesaler and supplier of the premium quality LX3 4D Colour Doppler Ultrasound Machine. It consists of adjusting multiple parameters, user interaction the system, improved color sensitivity, better flow aesthetics, etc. The offered range is designed under the directions of our team of well-experienced professionals, by using the quality-tested materials and ultra-modern techniques. Further, we are providing the range LX3 4D Colour Doppler Ultrasound Machine in various specifications and at market leading prices.

TECHNICAL DETAIL

Scanning mode  :-

• B-mode
• M-mode
• Anatomic M Mode 3 Lines
• TGC & LGC
• Color Doppler &Power Doppler Imaging/ with Adaptive Doppler Imaging
• Trapezoidal Imaging
• Directional PDI
• Digital ZOOM
• Dedicated Steer Control
• Special Compound Imaging (SCI)
• Auto IMT
• Pulsed Wave Doppler
• Continuous Wave Doppler (CW Doppler)
• HPRF(High Pulse Repetition Frequency)
• Static 3D / 4D Package
• TDI(including Color-TDI and PW-TDI)
• 5-Active Transducer Ports
• Battery Back-Up Rechargeable Li-Ion Battery with Level Display in Main Screen and Charging Indicator
• Removable GEL Warmer optional
• Built In DVD Drive optional
• WIFI Module
• USB 3.0 (One) & USB 2.0 (Six)
• HDMI & Ethernet
• DICOM Standard
• System dynamic Range   :- 0-264

Monitor :-

• 21.5 high resolution TFT LCD monitor
• Tilt: 30 upward, 90 downward
• Swivel: +/-90,  View angle: right 89,left 89,up 89,down 89
• Built-in stereo speaker ,- Brightness and Contrast adjustable

Touch screen:-

• 14 Touch screen
• Gesture-control
• User configurable UI
• Support QWERTY keyboard for text input
• Brightness adjustable
• Integrated user interface with ergonomic height adjustment design

Transducer port :-

• 5 active ports
• 5holders (1 dedicated for endocavity transducer)
• Electronic Transducer Selection

Control Panel:-

• Interactive back-lighting
• Hard Keys provides tactile feedback
• Programmable store keys
• Physical trackball
• 8 segment TGC sliders
• Wireless keyboard

Imaging storage:-

• 120 GB SSD
• Storage up to approximately > 400,00 lossless single frames
• Compression types of static image and clip: lossless, high, mid, low

Image processioning :

• Tissue Adaptive Imaging (TAI)
• Adaptive Doppler imaging  Frequency Compounding Imaging , Adaptive Spatial Compounding Imaging , Harmonic Imaging , Adaptive Speckle Reduction Imaging (eSRI)
• Spectrum Enhancement ,- B mode Auto Optimization ,- Color mode Auto Optimization
• PW mode Auto Optimization
• Digital Multi-Beam Beamforming - Up to 2949120 digital channels
• Trapezoid Imaging for linear transducer
• B Steer , Pan Zoom , Spot Zoom
• Full screen imaging.
• Needle Enhancement Visualization Imaging

Connectivity :

• Verify SCP ,Static image store SCU
• Ultrasound multi-image store SCU
• Four levels of compression ,Data transfer options
• Removable media ,In-progress network storagein background
• Auto-transfer in background at exam end Manual-transfer in background on demand
• 6 USB Ports (4USB 2.0 and 2 USB 3.0)

Video out:

• VGA,DVI, S-video: PAL/NTSC, -Ethernet.
• ECG port (inactive)
• Standard DVD-R/RW
• Wi-Fi
• DICOM Modality Work list ,- DICOM Structured Report: OB, GYN, Cardiac, and Vascular
• DICOM store to multiple networks ,- Non-DICOM network transfer(FTP transfer) in background
• Transfer management UI: review transfer task status, delete a transfer task
• DICOM Print, Support printing image via the DICOM printer connected to a DICOM server.
• DICOM MPPS
• Biopsy guide :  Optional Available .

3D/4D :

• Acquisition Modes: 4D, Static 3D
• Visualization Modes: Volume Rendering, PRs, Multi-Slice
• VOI adjustable: curve cut plane
• Render Modes: Surface, MIP, X-Ray
• 3D Clip (2D capture of 3D images)

Cut

• Cut tool: trace, box, erase
• Function: undo, undo all, redo
• Display formats: Single 3D, Dual(A-plane + 3D), Quad(A/B/C Planes + 3D)
• Parameters for 3D: Threshold, Smooth, Brightness, Contrast, Tint
• eFace: Edan Auto show face
• Save and edit volume data set

Post-Processing :

• B Mode: gain, TGC, zoom, dynamic range, eSRI, colorize, map
• M Mode: gain, TGC, dynamic range, colorize, map
• Color Mode: zoom, color map, invert
• PW/CW: gain, dynamic range, colorize, map, baseline, angle, invert
• Support review images and reportof an exam
• Support export images as BMP , AVI or DCM format to removable disk or DVD-R/RW
• Support export images as DCM format to DVD-R/RW
• Support import/export exams(including patient information, images, measurement results)
•  Support comments, body mark and measurements in revie
